E-Plex 3000/5000 Software 3.1 (EP-STD-03-001)

E-Plex 3000/5000 Software 3.1 (EP-STD-03-001)

Many of the E-Plex locks are stand-alone access control and do not require software, but the E-Plex line also offers several software management options that will make updating and managing your access control system efficient and effective. The E-Plex Standard Software allows easy management of up to 10,000 doors per site via a Microsoft Excel-based solution.

The E-Plex Standard Software is a simple Microsoft Excel-Based solution that manages up to 300 users per door, up to 10,000 doors per site, and multiple sites, plus users can be quickly added, deleted, or suspended.

Technical Details:

• PC Hardware: IBM compatible PC with Microsoft Windows
• Operating System: Microsoft Windows (not supplied)
• Microsoft Excel: For the most current information regarding this specification, please refer to documentation below
• Portable Maintenance Unit (M-Unit): Netbook or a mini Laptop PC with Microsoft Windows
• Note: The PC M-Unit (Laptop or Netbook) requires E-Plex M-Unit Kit as an accessory; the kit contains a USB flash drive and an IrDA adaptor

Easy to Use:

• Point-and-click Microsoft Excel-based software requires no special knowledge to operate
• One software supports E-Plex 1500, 2000, 3000, 5000 and PowerPlex 2000 Series locks
• Software provides simple on-screen instructions
• Instructions guide users through set-up, managing users and doors and establishing authority levels

Capabilities:

• Easily manages up to 300 unique Access Codes (PINs) per door (100 codes on E-Plex 1500 / 2000 and PowerPlex 2000)
• Manages up to 10,000 doors per site
• Users and doors are quickly added and deleted
• Includes optional built-in random PIN code generator

Simplified Setup:
Predefined spreadsheet templates simplify set-up and data input
Lock settings and related parameters are easily cloned, permitting quick multi-lock installations

Data Protection:
Passwords ensure integrity of system and data

Data Transfer:
Locks programmed and audits downloaded with handheld PC M-Unit (Maintenance Unit)
Communicates through infrared data transfer—just point a PC M-Unit at the lock’s transfer window

LED Indicators:
Provide visual confirmation during data transfer

Battery Life:
PC M-Unit quickly reads and displays lock’s battery status without having to access door

Audit Information:
Locks record last 9,000 Events (1,000 Events on E1500 and E/P2000 Series) to provide increased accountability; audit includes records of mechanical key override use

Data:
Audits are downloaded to Excel spreadsheets where information is easily analyzed, sorted or printed according to your needs—unlike the "canned" pre-programmed audits found in most access control systems

Authority Levels:
Five levels control who has access to specific lock functionsMaster—programs all lock functions (one Master per system)

• Manager—programs most lock functions
• Access User—authorized to gain access through PIN only
• Service Level—provides one-time access or "come-and-go" access for 1 to 24 hours—perfect for service personnel, meeting rooms, and rental spaces
• Communication Level—only authorized to program, send/receive audit files and check battery status without access to door or the ability to view access codes (one per system)

Assignment:
Each site is assigned one Master Level and one Communications Level—remaining codes set to any authority level

Flexibility:
Three modes to accommodate security and convenience needs during the business day

• PIN Access—access granted when valid PIN is entered
• Passage—can be toggled on/off or can be pre-programmed to re-lock after a certain number of hours, from 1 to 24 hours. Additionally, for the E-Plex 3000 locks, you can also have a "latch holdback" similar to passage mode.
• Lockout—denies access to all users except for Master code and mechanical key-override

Customizable User Preferences:

• Code Length: Accepts 4 to 8 digits
• Anti-Tamper Lockout: Adjustable from 0 to 90 seconds—activation set for 3 to 9 invalid entry attempts
• Re-Lock Time: Adjustable from 2 to 20 seconds
